6.3.8 6-** Analog In/Out
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
6-0* Analog I/O Mode
6-00 Live zero timeout time 10 s All set-ups TRUE 0 Uint8
6-01 Live zero timeout function [0] Off All set-ups TRUE - Uint8
6-1* Analog Input 1
6-10 Terminal 53 low voltage 0.07 V All set-ups TRUE -2 Int16
6-11 Terminal 53 high voltage 10.00 V All set-ups TRUE -2 Int16
6-12 Terminal 53 low current 0.14 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 high current 20.00 mA All set-ups TRUE -5 Int16
6-14 Terminal 53 low ref./feedb. value
0 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
6-15 Terminal 53 high ref./feedb. value App.Dependent All set-ups TRUE -3 Int32
6-16 Terminal 53 filter time constant 0.001 s All set-ups TRUE -3 Uint16
6-2* Analog Input 2
6-20 Terminal 54 low voltage 0.07 V All set-ups TRUE -2 Int16
6-21 Terminal 54 high voltage 10.00 V All set-ups TRUE -2 Int16
6-22 Terminal 54 low current 0.14 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 high current 20.00 mA All set-ups TRUE -5 Int16
6-24 Terminal 54 low ref./feedb. value
0 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
6-25 Terminal 54 high ref./feedb. value App.Dependent All set-ups TRUE -3 Int32
6-26 Terminal 54 filter time constant 0.001 s All set-ups TRUE -3 Uint16
6-3* Analog Input 3
6-30 Terminal X30/11 low voltage 0.07 V All set-ups TRUE -2 Int16
6-31 Terminal X30/11 high voltage 10.00 V All set-ups TRUE -2 Int16
6-34 Term. X30/11 low ref./feedb. value
0 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
6-35 Term. X30/11 high ref./feedb. value App.Dependent All set-ups TRUE -3 Int32
6-36 Term. X30/11 filter time constant 0.001 s All set-ups TRUE -3 Uint16
6-4* Analog Input 4
6-40 Terminal X30/12 low voltage 0.07 V All set-ups TRUE -2 Int16
6-41 Terminal X30/12 high voltage 10.00 V All set-ups TRUE -2 Int16
6-44 Term. X30/12 low ref./feedb. value
0 ReferenceFeed-
backUnit All set-ups TRUE -3 Int32
6-45 Term. X30/12 high ref./feedb. value App.Dependent All set-ups TRUE -3 Int32
6-46 Term. X30/12 filter time constant 0.001 s All set-ups TRUE -3 Uint16
6-5* Analog Output 1
6-50 Terminal 42 output null All set-ups TRUE - Uint8
6-51 Terminal 42 output min scale 0.00 % All set-ups TRUE -2 Int16
6-52 Terminal 42 output max scale 100.00 % All set-ups TRUE -2 Int16
6-53 Term 42 output bus ctrl 0.00 % All set-ups TRUE -2 N2
6-54 Terminal 42 output timeout preset 0.00 % 1 set-up TRUE -2 Uint16
6-55 Analog output filter [0] Off 1 set-up TRUE - Uint8
6-6* Analog Output 2
6-60 Terminal X30/8 output null All set-ups TRUE - Uint8
6-61 Terminal X30/8 min. scale 0.00 % All set-ups TRUE -2 Int16
6-62 Terminal X30/8 max. scale 100.00 % All set-ups TRUE -2 Int16
6-63 Terminal X30/8 bus control 0.00 % All set-ups TRUE -2 N2
6-64 Terminal X30/8 output timeout preset 0.00 % 1 set-up TRUE -2 Uint16
6-7* Analog Output 3
Programming Operating Instructions
MG37A202 Danfoss A/S © Rev. 2014-07-29 All rights reserved. 83
