6.3.15 14-** Special Functions
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
14-0* Inverter Switching
14-00 Switching pattern null All set-ups TRUE - Uint8
14-01 Switching frequency null All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-04 PWM random [0] Off All set-ups TRUE - Uint8
14-06 Dead time compensation [1] On All set-ups TRUE - Uint8
14-1* Mains On/Off
14-10 Mains failure [0] No function All set-ups FALSE - Uint8
14-11 Mains voltage at mains fault App.Dependent All set-ups TRUE 0 Uint16
14-12 Function at mains imbalance [0] Trip All set-ups TRUE - Uint8
14-13 Mains failure step factor 1.0 N/A All set-ups TRUE -1 Uint8
14-14 Kin. backup time out 60 s All set-ups TRUE 0 Uint8
14-2* Trip Reset
14-20 Reset mode [0] Manual reset All set-ups TRUE - Uint8
14-21 Automatic restart time App.Dependent All set-ups TRUE 0 Uint16
14-22 Operation mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode setting null 2 set-ups FALSE - Uint8
14-24 Trip delay at current limit 60 s All set-ups TRUE 0 Uint8
14-25 Trip delay at torque limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip delay at inverter fault App.Dependent All set-ups TRUE 0 Uint8
14-28 Production settings [0] No action All set-ups TRUE - Uint8
14-29 Service code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30 Current lim ctrl, proportional gain 100 % All set-ups FALSE 0 Uint16
14-31 Current lim ctrl, integration time 0.020 s All set-ups FALSE -3 Uint16
14-32 Current lim ctrl, filter time 1.0 ms All set-ups TRUE -4 Uint16
14-35 Stall protection [1] Enabled All set-ups FALSE - Uint8
14-4* Energy Optimising
14-40 VT level 66 % All set-ups FALSE 0 Uint8
14-41 AEO minimum magnetisation App.Dependent All set-ups TRUE 0 Uint8
14-42 Minimum AEO frequency 10 Hz All set-ups TRUE 0 Uint8
14-43 Motor cosphi App.Dependent All set-ups TRUE -2 Uint16
14-5* Environment
14-50 RFI filter [1] On 1 set-up x FALSE - Uint8
14-51 DC link compensation [1] On 1 set-up TRUE - Uint8
14-52 Fan control [0] Auto All set-ups TRUE - Uint8
14-53 Fan monitor [1] Warning All set-ups TRUE - Uint8
14-55 Output filter [0] No Filter All set-ups FALSE - Uint8
14-56 Capacitance output filter App.Dependent All set-ups FALSE -7 Uint16
14-57 Inductance output filter App.Dependent All set-ups FALSE -6 Uint16
14-59 Actual number of inverter units App.Dependent 1 set-up x FALSE 0 Uint8
Programming Operating Instructions
92 Danfoss A/S © Rev. 2014-07-29 All rights reserved. MG37A202
66
