6.3.16 15-** Drive Information
Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
15-0* Operating Data
15-00 Operating hours 0 h All set-ups FALSE 74 Uint32
15-01 Running hours 0 h All set-ups FALSE 74 Uint32
15-02 kWh counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power ups 0 N/A All set-ups FALSE 0 Uint32
15-04 Over temps 0 N/A All set-ups FALSE 0 Uint16
15-05 Over volts 0 N/A All set-ups FALSE 0 Uint16
15-06 Reset kWh counter [0] Do not reset All set-ups TRUE - Uint8
15-07 Reset running hours counter [0] Do not reset All set-ups TRUE - Uint8
15-1* Data Log Settings
15-10 Logging source 0 2 set-ups TRUE - Uint16
15-11 Logging interval App.Dependent 2 set-ups TRUE -3 TimD
15-12 Trigger event [0] False 1 set-up TRUE - Uint8
15-13 Logging mode [0] Log always 2 set-ups TRUE - Uint8
15-14 Samples before trigger 50 N/A 2 set-ups TRUE 0 Uint8
15-2* Historic Log
15-20 Historic log: event 0 N/A All set-ups FALSE 0 Uint8
15-21 Historic log: value 0 N/A All set-ups FALSE 0 Uint32
15-22 Historic log: time 0 ms All set-ups FALSE -3 Uint32
15-3* Fault Log
15-30 Fault log: error code 0 N/A All set-ups FALSE 0 Uint8
15-31 Fault log: value 0 N/A All set-ups FALSE 0 Int16
15-32 Fault log: time 0 s All set-ups FALSE 0 Uint32
15-4* Drive Identification
15-40 FC type 0 N/A All set-ups FALSE 0 VisStr[6]
15-41 Power section 0 N/A All set-ups FALSE 0 VisStr[20]
15-42 Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
15-43 Software version 0 N/A All set-ups FALSE 0 VisStr[5]
15-44 Ordered typecode string 0 N/A All set-ups FALSE 0 VisStr[40]
15-45 Actual typecode string 0 N/A All set-ups FALSE 0 VisStr[40]
15-46
Frequency converter ordering
no 0 N/A All set-ups FALSE 0 VisStr[8]
15-47 Power card ordering no 0 N/A All set-ups FALSE 0 VisStr[8]
15-48 LCP ID no 0 N/A All set-ups FALSE 0 VisStr[20]
15-49 SW ID control card 0 N/A All set-ups FALSE 0 VisStr[20]
15-50 SW ID power card 0 N/A All set-ups FALSE 0 VisStr[20]
15-51
Frequency converter serial
number 0 N/A All set-ups FALSE 0 VisStr[10]
15-53 Power card serial number 0 N/A All set-ups FALSE 0 VisStr[19]
15-59 CSIV filename App.Dependent 1 set-up FALSE 0 VisStr[16]
Programming Operating Instructions
94 Danfoss A/S © Rev. 2014-07-29 All rights reserved. MG37A202
