5.3.1 Ordering Numbers: Brake Resistors 10%
FC 360 P
m (HO)
R
min
R
br. nom
R
rec
P
br avg
Code no. Period Cable cross
section
2
*
Therm.
relay
Max. brake
torque
with R
rec
*
T4 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s]
[mm
2
]
[A] [%]
HK37 0.37 890 1041.98 989 0.030 3000 120 1.5 0.3 139
HK55 0.55 593 693.79 659 0.045 3001 120 1.5 0.4 131
HK75 0.75 434 508.78 483 0.061 3002 120 1.5 0.4 129
H1K1 1.1 288 338.05 321 0.092 3004 120 1.5 0.5 132
H1K5 1.5 208 244.41 232 0.128 3007 120 1.5 0.8 145
H2K2 2.2 139 163.95 155 0.190 3008 120 1.5 0.9 131
H3K0 3 100 118.86 112 0.262 3300 120 1.5 1.3 131
H4K0 4 74 87.93 83 0.354 3335 120 1.5 1.9 128
H5K5 5.5 54 63.33 60 0.492 3336 120 1.5 2.5 127
H7K5 7.5 38 46.05 43 0.677 3337 120 1.5 3.3 132
H11K 11 27 32.99 31 0.945 3338 120 1.5 5.2 130
H15K 15 19 24.02 22 1.297 3339 120 1.5 6.7 129
H18K 18.5 16 19.36 18 1.610 3340 120 1.5 8.3 132
H22K 22 16 18.00 17 1.923 3357 120 1.5 10.1 128
H30K 30 11 14.58 13 2.576 3341 120 2.5 13.3 150
H37K 37 9 11.71 11 3.206 3359 120 2.5 15.3 146
H45K 45 8 9.58 9 3.921 3065 120 4 20 150
H55K 55 6 7.80 7 4.816 3070 120 6 26 150
H75K 75 4 5.68 5 6.612 3231 120 10 36 150
Table 5.4 FC 360 - Mains: 380-480 V (T4), 10% Duty Cycle
Type Code and Selection
VLT
®
AutomationDrive FC 360 Design Guide
MG06B202 - VLT
®
is a registered Danfoss trademark 65
5 5
