GAIN adjustment
The GAIN adjustment can automatically adjust the scaling factor of the selected channel to only
nines. For example, 999999 for the WA command.
To auto-adjust to a specific value, use the “Esc” DASET command. (DAC setting in Amps)
To activate the automatic GAIN adjustment the following steps must be performed:
Select SW3 as above “setting number15".
Select the desired channel number “lever 1 to 5" on SW4.
Set on SW4 lever 8 to ON and lever 7 to OFF.
Set the output signal to 100% with the DA or the WA command.
Press the Setup button.
To restore the Gain value to the default factory setting, set lever 7 to 1 before pressing the
Setup button.
Channel Value DA channel spec. Equal to
0 Output current 16 bit WA range as default
1 Not used
2 Not used
3 Not used
4 Output voltage 16 bit
