System 9700 User Manual
Page 45 of 56
The following are the setup commands in alphabetical order.
Please see the SW appendix 1 for parameter formats and further detail explanation.
‘esc’ SET UP COMMANDS. Summary
ESC<AD Configures the AD converter attaining
and routing (Output reading
adjustment or output reading in % or
Amps).
ESC<ADR Configures the communication address
setting (in RS422 mode).
ESC<ADSET Auto Configures the scaling “gain” and
Offset for an AD converter channel.
ESC<AUX Configures the special options.
ESC<BAUD Configures the Baud rate for the serial
lines.
ESC<COLDBOOT
Configures the power up state (Wake
up position)
ESC<CPURESET
Hardware reset / CPU reset.
ESC<DA Configures the Digital to Analog
converters. (Slew rate setting in A/sec
or set value in Amps).
ESC<DASET Auto Configures the scaling (gain) and
Offset for a DA converter channel.
ESC<LINE Configures the protocol for the serial
lines.
ESC<POLDELAY
Configures the delay between off and
polarity switch change.
The following are commands for the software driven “RAMP PROFILE” listed in alphabetical
order. See the SW manual for parameter formats and further detailed descriptions.
These commands are optionally available.
SW RAMP PROFILE COMMANDS “Arbitrary point method”. Summary
CONT Continue sequence operation.
CSS Clear sequence stack and pointers.
FAST Fast sequence timing.
HALT Halt sequence operation.
MULT Reads the multiplying factor for the
DAC scaling.
MULT X Writes a multiplying factor for the DAC
scaling.
RRSP Reset read sequence pointer.
RSA Read sequence and auto increment.
RSP Read sequence position.
RWSP XX Reset write pointer.
S2 Read sequence status.
SLOW Slow sequence timing.
SPEED Read sequence timing.
STOP Stop sequence executing.
SYNC Synchronization of sequence.
TS Trig sequence.
WSA Write sequence and auto increment.
WSP Write Sequence position.
OPTIONAL SW RAMP PROFILE COMMANDS for “Equal time slot method” (summary)
R Writes data to the stack.
RAMP [RSHT],[LWB]
Controls the stack operation.
RAMPSET Time,Multiplicant,TrDly [LWN],C
Configures the ramp operation.
