Dascom DC-7600 User Guide V1.0
Component Name Function
Top cover Open when loading cards or cleaning the feeding roller.
Control panel
Includes the keys, the LCD Panel, and LED indicator for operating the
printer.
Front cover
Open when changing print ribbons and retransfer film, and when
cleaning the Cleaning Roller.
Retransfer film lock
When loading retransfer film, move the lock switch away from
retransfer film cartridge to release.
Retransfer film
cartridge
Retransfer film. This is where you install retransfer (INTM) film
Ribbon cartridge Ribbon cartridge. This is where you install color print ribbon.
Rib cartridge lock When loading ribbon, move the lock switch away from print ribbon
cartridge to release.
Power switch Turns power on and off.
Front cover switch Front Cover opening switch. Press to open the Front Cover.
Handle Move the printer.
Cleaning module Remove when replacing the Cleaning Tape (or “roller”?).
