dap4 I/O Control Board and Unit Terminal Block Pin ID Number
Control & Alarms – Digital Outputs I/O Board Pin ID ID Connector Number Unit TB
System Blower NO1 J12-2 TB1-4
Compressor 1 NO2 J12-3 TB1-5
Compressor 2 NO3 J12-4 TB1-6
Opt Cooling 3rd Stage NO4 J13-2 TB2-37
Opt Cooling 4th Stage NO5 J13-3 TB2-38
Humidier NO6 J13-4 TB1-8
Status Contact
C7 J14-1 TB1-9
NO7 J14-2 TB1-10
CondenserAux
NO8 J15-1 TB2-47
C8 J15-2 TB2-46
Reheat 1 NO9 J16-2 TB1-7
Reheat 2 NO10 J16-3 TB1-20
Reheat 3 NO11 J16-4 TB1-21
Alarm 3
NO12 J17-1 TB1-45
C12 J17-2 TB1-43
NC-12 J17-3 TB1-44
Alarm 4 NO13 J18-1 TB2-50
C13 J18-2 TB2-48
NO13 J18-3 TB2-49
Alarm 1
NO14 J21-1 TB1-13
C14 J21-2 TB1-11
NC14 J21-3 TB1-12
Alarm 2
NO15 J21-4 TB1-42
C15 J21-5 TB1-40
NC15 J21-6 TB1-41
Opt Energy Saver NO16 J22-2 TB1-19
OptHumidierDrain(Autoush) NO17 J22-3 TB2-39
Control – Analog Output I/O Board Pin ID ID Connector Number Unit TB
Water Valve Control
Y1 J4-3 TB2-34
VG0 J4-2 TB2-35
OptHumidierModulatingControl
Y2 J4-4 TB2-51
VG0 J4-2 TB2-52
Blower Fan Speed Control
Y3 J4-5 TB4-1, 2
VG0 J4-2 TB4-3,4
SCR Reheat
Y4 J4-6 N/A
VG0 J4-2
