29•dap4UserManual
MENU I – MANUAL CONTROL
MENU I allows manually running different unit components (Service Level password is required for
entry).
In the Main Menu screen press the UP or DOWN key until “I. Manual Control” appears and is high-
lighted. Press the ENTER key.
The following will be displayed (values are for reference only):
Note: The “Return to Auto:” is programmable from 10 to 300 seconds. Once the time has
elapsed the functions will return to normal programmed operation.
Move the cursor to the title block by pressing the ENTER key. To return to the Main Menu press
the Esc key or to view the following screen press the DOWN key.
The following will be displayed (values are for reference only):
Move the cursor to the title block by pressing the ENTER key. To return to the Main Menu press
the Esc key or to view the following screen press the DOWN key.
The following will be displayed (values are for reference only):
Manual Output Mgmt: 1
Return to Auto: 60s
Blower Auto On
Compressor 1 Auto Off
Compressor 2 Auto Off
Compressor 3 Auto Off
Compressor 4 Auto Off
Manual Output Mgmt: 2
Humidifier Auto On
Status Relay Auto On
Cond Aux Rly Auto Off
Reheat 1 Auto Off
Reheat 2 Auto Off
Reheat 3 Auto Off
Manual Output Mgmt: 3
Energy Saver Auto Off
Alarm 1 Auto Off
Alarm 2 Auto Off
Alarm 3 Auto Off
Alarm 4 Auto Off
Drain Auto Off
