25•dap4UserManual
MENU F – INFORMATION
MENU F allows viewing of the processor version (Service Level password is required for entry).
This is a view only menu.
Once password has been entered scroll until Menu F – Information is highlighted. Press the
ENTERkeytoview.Theretwoscreens.Therstscreenwilldisplaythefollowing:
▼PresstheUPorDOWNkeytoviewsecondscreen.Thesecondscreenwilldisplaythe
following:
▼PresstheMENUkeytoreturntothemainmenuorpressEsctoreturntothenormaloperating
mode.
Information
Data Aire Inc.
Code:
Ver: 1.0B01 05/04/11
Manual code: 4.30 12/22/08
Boot: 4.03 07/03/06
Information
pCO Type: pCO5 Large
Total Flash 2048KB
RAM 512KB
Built-In Type
T Memory Write 0
Main Cycle/s
4.2 cycles/s 238ms
