Data Aire dap 4 User Manual

31•dap4UserManual
MENU J – FACTORY SETTINGS (factory use only)
IMPORTANT NOTE: MENU J is for setting the control to the type equipment and options ordered.
This requires the Factory Level password and entry should be limited to Data Aire factory
and service personnel. Consult with factory before making any changes to these factory settings.
Failure to do this may lead to equiipment malfunctions.
In the main menu screen press the UP or DOWN key until “J. Factory Settings” appears and is
highlighted. Press the ENTER key.
The following will be displayed:
The inputs are for reference only (see below for available settings).
Model: There are four choices – gForce, Mini, Mini-Plus and DA Series
Screen Flip Delay: The range is 0 to 99 seconds (in 1 second intervals)
Start-up Delay: The range is 5 to 600 seconds (in 1 second intervals)
Temp Units: Fahrenheit or Centigrade
OutStatus: Therearevechoices–SysOn,DehumOn,HumOn,CompsOn,and
Reheat On
Fan Type: There are two settings – Plug Fan, Std On/Off
Fan Mode: There are two choices - Continuous and Automatic
Onceinputshavebeenmade,movethecursor(bypressingtheENTERKey)tothetitlebox.
PresstheDOWNkeytoviewthenextscreen:
The following will be displayed (values are for reference only/see below for available settings):
Fan Settings (Plug Fan Only – Fan Type in rst screen must be set for PLUG FAN)
System Settings
Model: DA gForce
Screen Flip Delay: 3s
Start-up Delay: 5s
Temp Units: Fahrenheit
Out Status: Sys On
Fan Type: Plug Fan
Fan Mode: Continuous
Fan Settings
CW Mode: Const Speed
CW Speed: 85%
Disch Temp Is Required
DX Mode: Constant
DX Speed: 100%
Modulate Min: 40%
Modulate Max: 60%
