Data Aire gForce Ultra Installation, Operation & Maintenance Manual

gForce Ultra IOM
30
Factory Charge for Water/Glycol Cooled System
Evaporator Model
Total R-410A
Required (lbs.)
Variable Speed
Circuit (lbs.)
Fixed Speed
Circuit (Lbs.)
GUWX-022XX
GUGX-022XX
10
10
N/A
GUWX-036XX
GUGX-036XX
16
16
N/A
GUWX-045XX
GUGX-045XX
18
18
N/A
GUWX-070XX
GUGX-070XX
30
16.5
13.5
GUWX-091XX
GUGX-091XX
36
19.8
16.2
GUWX-125XX
GUGX-125XX
42
23.1
18.9
Connection Sizes, Water/Glycol Cooled Units
Table 7 Water/Glycol Cooled Units Connection Sizes
Evaporator Model
Water In Connection
Water Out Connection
GUWX-022XX
GUGX-022XX
1-1/8” (29mm) O.D.
1-1/8” (29mm) O.D.
GUWX-036XX
GUGX-036XX
1-5/8” (41mm) O.D.
1-5/8” (41mm) O.D.
GUWX-045XX
GUGX-045XX
1-5/8” (41mm) O.D.
1-5/8” (41mm) O.D.
GUWX-070XX
GUGX-070XX
1-5/8” (41mm) O.D.
1-5/8” (41mm) O.D.
GUWX-091XX
GUGX-091XX
2-1/8” (54mm) O.D.
2-1/8” (54mm) O.D.
GUWX-125XX
GUGX-125XX
2-1/8” (54mm) O.D.
2-1/8” (54mm) O.D.
