Error
Message
(LCD)
Error
Code
(LCD)
Meaning
Possible
Cause
Corrective Action
(Operator)
Status Code
Sent to
Application
Card
Processing
Status
Two cards in
card carriage
Remove cards from carriage or any
loose cards in system. Try sending
the card data again.
Embossing
Error
XXYY0D
XXYY0E
XXYY0F
XXYY10
XXYY12
XXYY13
XXYY14
The upper or
lower emboss
mechanism did
not find home
as expected.
Excessive
variation in the
card stiffness
or thickness
Remove cards from carriage or any
loose cards in system. Reinitialize
the system. Try sending the card
data again.
D = Wheel
Stepper Error
Card moved to
reject tray
Coordinate
Out Of Range
XXYY15 Data exceeds
physical limits
of the card
Too many
emboss
characters on
the card or
invalid
embossing
location
specified.
Send the same card data again. Try
sending a different customer record.
R = Embossing
limits exceeded
No card
processed
Command out
of sequence
XXYY16 Sensors in the
system did not
transition in the
expected
sequence.
Interlock
circuit opened
while picking
card.
Ensure that the cover is closed
properly and that the interlock
switch bracket is not bent.
M = Interlock
open
Card processing
stops
No cards
loaded
Load cards Card Supply
Empty
XXYY17 Card supply
sensor did not
transition as
expected.
Card weight
not installed
Install weight.
Z = Input hopper
empty
No card
processed
No cards in
input hopper,
card weight
installed
backwards.
Remove and reload cards. Install
card weight correctly.
Cards stuck
together
Fan cards before loading to remove
static. Reload cards.
Card Feed
Error
XXYY18 Card Picked
sensor did not
become
blocked as
expected.
Card weight
not installed
Remove and reload cards. Install
weight.
G = Card Feed
Error
Card in input
hopper or
magnetic stripe
module
Too many
single cards
inserted.
Remove all cards from the input
hopper and remove any jammed or
protruding cards. Reinitialize the
system.
Card Feed
Error
XXYY19 Card Picked
Sensor
remained
blocked after
transport
attempted to
pick card.
Card weight
not installed
Install weight.
G = Card Feed
Error
Card in Input
hopper or
magnetic stripe
module
None XXYY1A Requested
motor is on.
None None
None
XXYY1B User requested
motor stop.
None None
None
XXYY1C Illegal wheel
position
requested.
Flash memory
failure
Reinitialize system P = System Error No card
processed
