56 Printer Manager
Usingcustommagneticstripedataformatsisatwo‐stepprocess.First,definethe
customtracksusingMagStripeCustomTrack1,MagStripeCustomTrack2,and
MagStripeCustomTrack3.Second,applythecustomtrackusingthesettingson
theMagStripeGeneralmenu.
1. Tousethedefinedcustomtrack:
A. Openthe MagStripeGeneralmenu.
B. SelectCustomforDataFormat1,DataFormat2,orDataFormat3tousethe
customtrack.
• MagStripeCustomTrack1correspondstoDataFormat1
• MagStripeCustomTrack2correspondstoDataFormat2
• MagStripeCustomTrack3correspondstoDataFormat3
2. ClickSetCurrenttoapplythechanges.
Laminator
TheLaminatorsettingsletyouspecifyvalueswhenusingalaminatingsystem.
Description Default Value
Current Value
(unit)
Allowed
Range
1) DebowDelay 1000 1000 [0 – 1500]
2) ExceptionCardDebow
Direction
Down Down
3) ExceptionCardDebow
DistanceDown
15 15 [0 – 150]
4) ExceptionCardDebow
DistanceUp
105 105 [0 – 150]
5) ExceptionCardDebow
DwellMs
1000 1000 [0 – 5000]
6) ExceptionCardImpress
Depth
0 0 [-200 – 200]
7) ExceptionCardImpress
Dwelltime
2000 2000 [0 – 10000]
8) ExceptionCardImpress
PositionOffset1
2000 2000 [0 – 4000]
