DataCard SP55 User Manual

16
SP Series Production e-Guide
Replace the printhead cartridge
1 Position the printhead cartridge with the silver label toward you and on top. Place the printhead cable behind
the cartridge so the plug is visible through the opening in the printhead cartridge.
2 Carefully align the plug with the receptacle on the printhead. Push the plug all the way onto the receptacle (see
the following illustration).
3 Align the printhead cartridge pins with the printhead cartridge slots on the cover arm (see the following
illustration).

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
