DataCard SP55 User Manual

57
SP Series Install e-Guide
6 Use the following settings:
7 When the settings are correct, click OK to save settings and close the dialog box.
Setting a serial port for Windows Me or 98
1 From the Start menu, choose Settings and then Control Panel.
2 From the control panel, open System.
3 On the System Properties dialog box, click the Device Manager tab.
Setting Value
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Flow control None

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
