DataCard SP55 User Manual

59
SP Series Install e-Guide
8 Use the following settings:
9 When the settings are correct, click OK to save settings and close the dialog box.
Setting the serial port on Windows NT
1 From the Start menu, choose Settings and then Control Panel.
2 From the Control Panel, open Ports.
3 From the Ports dialog box, choose the port, such as COM1 or COM2.
4 Click the Settings button to display the port settings.
— If the PC has more than one serial port, make sure you view the settings for the serial port to which the
smart card is attached.
5 Use the following settings:
Setting Value
Bits per second 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
Setting Value
Baud rate 9600
Data bits 8
Parity None

DataCard SP55 Specifications

General

Print Technology	Dye Sublimation
Print Resolution	300 dpi
Print Capabilities	Full-color, monochrome
Card Capacity	100 cards (input hopper), 30 cards (output hopper)
Card Sizes	CR80 (85.6 mm x 54 mm / 3.375" x 2.125")
Connectivity	USB
Power Requirements	100-240 VAC, 50/60 Hz
Operating System Support	Windows 7, 8, 10
