Handbuch Datafox EVO 3.5 Pure Seite 115 Datum: 06.08.2018 Version: 04.03.07.XX
2. ) List / binary file sruckture
By the list configuration the list who has a binary field will be selected.
In this example, the value of the transponder reading, who is wanted in the list in the ID field. The
data that needs to be written is binary on the Data on Card field. The maximum field size is not al-
lowed to exceed more than 220 bytes.
After this, the further procedure can be set for list errors.
3. ) RFID configuration for „write on a RFID tag”
The transponder configuration for the reading can be freely selected. However, firstly it needs to be
defined in the basic transponder settings.
Please note:
First, complete the transponder configuration, then create the list with the binary field and
finally parameterize the field function Data on Card.
