Handbuch Datafox EVO 3.5 Pure Seite 128 Datum: 06.08.2018 Version: 04.03.07.XX
6. Technical specifications EVO 2.8 /3.5 Pure
EVO 3.5 Pure Terminal V4.X
Housing
Structure, Dimensions ( w x h x
d)
Plastic: ABS // 109 mm x 200 mm x 85 mm
Weight (Without power supply)
base unit 0,35 KG plus wall mount plate 0,125 KG
System
Clock
Real-time clock
Data storage
Flash
4 MB, 100,000 write cycles
Memory expansion (optional)
SD card, max 2 GB
Display
LCD
EVO 2.8: TFT: 320 x 240 Pixel, active area 57,6 x 43,2 mm mit LED-Backlight
EVO 3.5: TFT: 480 x 320 Pixel, active area 73,4 x 49,0 mm mit LED-Backlight
Keys
Type, size
EVO 2.8: Keyboard on touch screen, touch area 57,6 x 43,2mm
Life time according to manufacturer specification: 1 Mio. hits
EVO 3.5 Capacitive touch screen, touch area 73,4 x 49,0mm, touch wearless
Power
Power Supply
12 V DC
Power
Base unit 3 watts, depending on the equipment up to max. 10 W
Clock / RAM buffering
Goldcap, securing the time up to one week
Environment values
Ambient temperature
-20 ° C to +70 ° C (Power Supply -20 ° C to +60 ° C)
Protection
IP 54
Software
Configuration program
Setup program (Datafox-Studio) to configure without programming effort
Communication tools
http, DLL or C source code for inclusion in the application
Module extensions
For the extension to a variety of functions such as communication, inputs/outputs, sensors are 5 expansion slots for
modules
Data transmission zu
PC/Server
USB
Micro USB integrated
TCP / IP (optional)
TCP / IP operating with integrated TCP / IP stack, 10/100 Mbit
WLAN (optional)
integrated wireless LAN module, WLAN 802.11 bg and 802.11 n (only 2,4GHz)
GPRS (optional)
online via GPRS, mobile module quad band 850 / 900 / 1800 / 1900 MHz
RS485 (optional)
RS485 2-wire bus
USB host (optional)
for data transfer via USB stick, protection IP22
Bluetooth (optional)
Bluetooth module integrated; range up to max. 100 m
Readers Connection
RS232 external (optional)
Connection of bar code readers, magnetic card readers via mini-DIN connector
Access Options
RS485 external
Connection of up to 3 busses with up to 8 external door modules / access readers
each
Door lock relay with Door Moni-
toring
1 relay changeover , 30 V AC, 30 V DC, 2 A, max. 60 W, 1 digital input for door
monitoring, ...
MDE Options
Module digital inputs
4x digital input, electrically isolated, up to 100kHz, or 250Hz, Low 0,0...1,5V; High
3,5…30,0V
Module relay outputs
1 x NO, 1 x changeover contact, 30 V AC, 30 V DC, 2 A, max. 60 W
Module analog voltage inputs
4 x input, 15-bit resolution, accuracy ± 2% measuring range 0-10 V, other ranges
and functional insulation 230 V on request
Module analog inputs Current
4 x input, 15-bit resolution, accuracy ± 2%, measuring range 0-25 mA;
Functional insulation 230 V on request
Additional Options
Fingerprint
Fingerprint module integrated; sensor on the right below
Integrated transponder reader
125kHz, for example Unique, titanium, Hitag
13.56 MHz, e.g. Legic, Mifare, ISO14443, ISO15693, Simon Voss, iButton, Nedap
GPS receiver / receiver
50 Channels, GPS L1 frequency C / A, Galileo Open Service L1
Bar code scanner integrated
1D or 2D bar code scanner
Column
Column for free putting
7. FAQ
Eine umfangreiche Sammlung von FAQ finden Sie auf unserer Homepage:
http://www.datafox.de/faq-de.html
