Handbuch Datafox EVO 3.5 Pure Seite 22 Datum: 06.08.2018 Version: 04.03.07.XX
5.5. Connecting of EVO 2.8 /3.5 Pure Terminals
5.5.1. Connecting plugs
The EVO 3.5 Pure have intergatet 5 modulplaces. On this places can you order different modules.
You can choose the modules on the pricelist.
Steckerleiste des EVO 3.5 Pure V4
Bezeichnung
Modul
PIN
Beschreibung
Modulplatz 1
1
1
ground
2
A RS 485 for accesscontrol
3
B RS 485 for accesscontrol
4
12 V
Modulplatz 2
2
4-5
1-3
Standard:
1 digital input
1 digital output with nc and no contact
Modulplatz 3
3
1
1 digital input
2
2 digital input
3
3 digital input
4
4 digital input
5
ground
Modulplatz 7
RS 232
Mini-DIN M004
7
1
TXD
2
RXD
3
+ 5 V
4
Ground / GND
Modulplatz 8
8
TCP/IP - LAN
RJ 45
M1
SIM
12VDC
USB
GPRS
GPS
RS232
M7
LAN
M8
485-A
485-B
GND 
12 V
M3
D IN1
DGND
D IN2
D IN3
D IN4
M2
DGND
D IN1
ZK
M1
SIM
12VDC
USB
GPRS
GPS
RS232
M7
LAN
M8
485-A
485-B
12V 
GND
M3
M2
DGND
D IN1
Relais
ZK
485-A
485-B
HK
Variante mit RS485 Haupt-
kommunikation
