Here you will find a whole series of important information about the terminal.
Here are some explanations of the individual lines:
1) Name of the setup, this is also available when reading out.
2) The date when the setup was loaded into the device.
3) State of the digital inputs. All inputs which are physically present and defined in the setup are displayed
here with their status.
a. 00000000 = Digital inputs defined in the setup
b. 0 = Input on low (logical 0)
c. 1 = Input on hi (logical 1)
4) If digital inputs are defined in the setup as counter, the current count value is displayed here.
5) Status of the digital outputs: Output 1 is continuous here from left to right.
6) Analog inputs from left to right with respective currently applied voltage.
7) Number of stored records in the device and memory used.
1
2
3
4
5
6
7
