Datalogic DX8200A

INSTALLATION
2
2.3 ELECTRICAL CONNECTIONS
All the connectors available for each scanner model are the following:
Scanner Model Connectors
Standard 26-pin male serial interface and I/O connector
17-pin male Lonworks connector
17-pin female Lonworks connector
Ethernet 26-pin male serial interface and I/O connector
17-pin male Lonworks connector
17-pin female Lonworks connector
RJ45 Industrial modular connector
Profibus 26-pin male serial interface and I/O connector
17-pin male Lonworks connector
17-pin female Lonworks connector
Profibus 9-pin female connector
DeviceNet 26-pin male serial interface and I/O connector
17-pin male Lonworks connector
17-pin female Lonworks connector
DeviceNet 5-pin male connector
7
