Datalogic DX8200A Reference Manual

TECHNICAL FEATURES
7
7 TECHNICAL FEATURES
ELECTRICAL FEATURES
VAC models VDC models
Supply voltage 110 to 230 Vac 20 to 30 Vdc
Power consumption 30 VA typical 30 W typical
35 W Max. (including startup current)
Main Baud Rate
RS232
RS485 full-duplex
RS485 half-duplex
1200 to 115200
20 mA C.L.
(INT-30 with C-BOX 100 only)
19200
Auxiliary
RS232 1200 to 115200
Other
Common Communication
Interfaces
Lonworks 1,25 Mb/s
Model–Dependent Communication
Interfaces
Ethernet
Profibus
DeviceNet
100 Mb/s
up to 12 Mb/s
up to 500 Kb/s
Inputs
Ext. Trigger 1,
3 aux. digital inputs
(optocoupled NPN or PNP)
Outputs
3 software programmable digital
outputs
(optocoupled)
OPTICAL FEATURES
Light receiver Avalanche photodiode
Wavelength 630 to 680 nm
Safety class Class 2 - EN60825-1; Class II - CDRH
Light source Up to 4 semiconductor laser diodes
Laser control Security system to turn laser off in case of motor slow
down
READING FEATURES
Scan rate
≤ 1000 scans/s (500 per leg)
Maximum resolution
Max. reading distance
Max. reading width
Max. depth of field
(see reading diagrams in par. 4.4)
USER INTERFACE
LCD Display 2 lines by 20 characters LCD
Keypad 3 keys
LED indicators Power On (green)
Phase On (yellow)
Encoder (yellow)
TX Data (green)
Network (red)
73

Datalogic DX8200A Specifications

General

Scan speed	1000 sec/page
Sensor type	Laser
Dimensions (WxDxH)	470 x 300 x 147 mm
Standard interfaces	RS-232, RS-485
Power requirements	30 VCD
Power consumption (standby)	30 W
Keys quantity	3 keys
Product color	Black
LED indicators	Charging, Power
Housing material	Steel
International Protection (IP) code	IP64
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	11000 g
