Datalogic DX8200A

DX8200A
2
30
CAB601X
C-BOX 100
DX8200A
Master
AUX
DS4600A
Slave 1
MAIN
1
P.S.*
2
1
Local Host
2
C-BOX 100
DS4600A
Slave 2
PWR-120
C-BOX 100
1
1
2
Main Serial Interface
A
uxiliary Serial Interface
* P.S. (Presence Sensor) connected to External Trigger/PS input.
Figure 35 – RS232 Master/Slave for DX8200A Standard Models
Remote PLC
DX8200A
Master
CAB601X
Fieldbus
Network
C-BOX 100
AUX
DS4600A
Slave 2
P.S.*
2
1
C-BOX 100
DS4600A
Slave 1
PWR-120
C-BOX 100
2
1
2
Main Serial Interface
A
uxiliary Serial Interface
* Presence Sensor connected to
External Trigger/PS input.
1
Figure 36 – RS232 Master/Slave for DX8200A Fieldbus Models
