Datalogic DX8200A

READING FEATURES
4
DX8200A-3X2X (0.30 mm/12 mils)
The diagram shows an average reading area obtained considering different barcode types of
variable quality.
0 -16 -32
(in)
-24 -40 -48 -56
-40 -60
(cm)
-80 -100 -120 -140
(in)
-30
-20
0
-10
(cm)
-50
-60
-40
30
20
10
50
60
40
-12
-8
0
-4
-20
-24
-16
12
8
4
20
24
16
70
28
0
x
z
Note: x = 0 and z = 0 correspond to the edge of the DX8200A scanner as shown in the figure above.
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
