GRYPHON™ I GBT/GM4200
READER, CRADLE
AND LEDS DESCRIPTION
LEDs on the gun provide information about the battery
charging status as well as data transmission.
Figure 3 - Gryphon Base LEDs
1. Scan Window
2. Trigger
3. Battery & Recharge LED
4. Good Read LED
1. Capacitive Touch Service Button
2. Power LED
3. Recharge LED
4. Communication Port
