Using the GBT/GM4200 scanner
8 GRYPHON™ I GBT/GM4200
USING THE GBT/GM4200 SCANNER
Scanner LEDs
Specific LEDs on the Gryphon Scanner provide information
about good reading result (3GL) and battery status.
The Battery Status information can be easily retrieved by
double-tapping with your fingers on top of the head of the
scanner. The following table lists the battery status LED
colors and their meaning.
Table 1 - Battery LED
USING THE WLC4190 RADIO BASE
Radio Base LEDs
LEDs on the Gryphon Base provide information about the
Base as well as battery charging status, as shown in Figure 10.
Figure 10 - Gryphon Base LEDs
COLOR BATTERY STATUS
Solid color (3s time-out):
• Green
• Amber
Red blinking
charge = 50% - 100%
charge = 2% - 50%
charge less than 2%
