Datalogic GRYPHON User Manual

TECHNICAL FEATURES
163
GRYPHON™ D/M READER DATA ENTRY
Beeper¹
LED Good Read Spot Meaning
one beep²
ON ON Correct read of a code in normal mode
H L long TX buffer full (when FIFO is enabled) or TX
error between Gryphon™ M and
OM-Gryphon™
H long ON ON Successful advanced format concatenation
H H H Timeout expired – operation not completed
H H long Error in advanced data formatting
OFF OFF Ready to read a code
GRYPHON™ M POWER
Beeper LED Meaning
10 short H 10 short blinks Low Battery
GRYPHON™ M BIND, JOIN, COPY COMMANDS
Beeper¹
LED Meaning
Blinking Command accepted; reader ready to be inserted into
the cradle
L Success
H L long tones Failure
¹ Only the Beeper Intensity command can modify these signals.
² The data entry good read tone is user-configurable with all
the Beeper commands
in the Reading Parameters section.
For M-Series readers, normally this results in two beeps; the first indicates that the
reader has decoded the code, the second indicates whether OM-Gryphon™ has
received the data. See also par. 5.8.3.

Datalogic GRYPHON Specifications

General

Scanner Type	Handheld
Category	Barcode Reader
Drop Resistance	1.8 meters
IP Rating	IP65
Decoding Capability	1D and 2D barcodes
Light Source	LED
Scan Pattern	Linear or omnidirectional (depending on model)
Model	GRYPHON
Type	Handheld
Scan Technology	Laser or Imager (depending on model)
Humidity	5 to 95% NC (Non-Condensing)
Dimensions	Varies by model
Weight	Varies by model
Power Supply	Battery (Cordless Models)
Storage Temperature	-20°C to 60°C
