Host Transmission Buffers
222222
Baud Rate
9600 9600 9600 9600 9600 9600
Data Bits
888888
Stop Bits
111111
Parity
None None None None None None
Hardware Flow Control
Disable Disable Disable Disable Disable Disable
Intercharacter Delay
No Delay No Delay No Delay No Delay No Delay No Delay
Software Flow Control
Disable Disable Disable Disable Disable Disable
Host Echo
Disable Disable Disable Disable Disable Disable
Host Echo Quiet Interval
10 msec 10 msec 10 msec 10 msec 10 msec 10 msec
Signal Voltage: Normal/TTL
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
RS-232 Invert
Disable Disable Disable Disable Disable Disable
Beep on ASCII BEL
Enable Enable Enable Enable Enable Enable
Beep on Not on File
Enable Enable Enable Enable Enable Enable
ACK NAK Options
Disable Disable Disable Disable Disable Disable
ACK Character
006 006 006 006 006 006
NAK Character
021 021 021 021 021 021
Retry on ACK NAK Timeout
Enable Enable Enable Enable Enable Enable
ACK NAK Timeout Value
001 001 001 001 001 001
ACK NAK Retry Count
003 003 003 003 003 003
ACK NAK Error Handling
Ignore Ignore Ignore Ignore Ignore Ignore
Transmission Failure Indication
Enable Enable Enable Enable Enable Enable
Single Cable RS-232 Options
RTS held
high, wait
for CTS to
be
asserted
Single Cable RS-232 Use BCC
Enable
Single Cable RS-232 Use ACK/NAK
Enable
Single Cable RS-232 Use STX
Enable
Set Single Cable RS-232 STX Character
53
Single Cable RS-232 Use ETX
Enable
FEATURE Aux RS-232
Wincor-
Nixdorf
Single
Cable
USB-OEM
Keybd
Wedge
