Datalogic MAGELLAN 3200VSI - Page 177

Keyboard Model Cross Reference
Product Reference Guide 169
Table E-3. Scanset 1 Function Key Map
Table E-4. Scanset 2 Function Key Map
ASCII
(hex)
ASCII code Key Scancode
02 STX ALT left Make 38h
03 ETX ALT left Break B8h
04 EOT CTRL left Make 1Dh
05 ENQ CTRL left Break 9Dh
06 ACK CTRL right Make E0h 1Dh
07 BEL CTRL right Break E0h 9Dh
08 BS BS 0Eh
09 HT TAB right 0Fh
0A LF RIGHT arrow (inner keypad) 4Dh + E0
0B VT TAB left 0Fh + S
0C FF Enter (inner keypad) 1Ch + E0
0D CR CR 1Ch
0E SO INSERT (inner keypad) 52h + E0
0F SI PAGE UP (inner keypad) 49h + E0
10 DLE PAGE DOWN (inner keypad) 51h + E0
11 DC1 HOME (inner keypad) 47h + E0
12 DC2 LEFT arrow (inner keypad) 4Bh + E0
13 DC3 DOWN arrow (inner keypad) 50h + E0
14 DC4 UP arrow (inner keypad) 48h + E0
ASCII
(hex)
ASCII code Key Scancode
02 STX ALT left Make 11h
03 ETX ALT left Break F0h 11h
04 EOT CTRL left Make 14h
05 ENQ CTRL left Break F0h 14h
06 ACK CTRL right Make E0h 14h
07 BEL CTRL right Break E0h F0h 14h
08 BS BS 66h
09 HT TAB right 0Dh
0A LF RIGHT arrow (inner keypad) 74h + E0
0B VT TAB left 0Dh + S
0C FF Enter (right keypad) 5Ah + E0
0D CR CR 5Ah
0E SO INSERT (inner keypad) 70h + E0
0F SI PAGE UP (inner keypad) 7Dh + E0
10 DLE PAGE DOWN (inner keypad) 7Ah + E0
11 DC1 HOME (inner keypad) 6Ch + E0
12 DC2 LEFT arrow (inner keypad) 6Bh + E0
13 DC3 DOWN arrow (inner keypad) 72h + E0
14 DC4 UP arrow (inner keypad) 75h + E0
15 NAK F6 0Bh
16 SYN F1 05h
17 ETB F2 06h
18 CAN F3 04h
19 EM F4 0Ch
1A SUB F5 03h
1B ESC ESC 76h
1C FS F7 83h
