Symbologies
180 QuickScan® QD2100
Code 128 — cont.
Code 128 Length Control
This feature specifies either variable length decoding or fixed length decoding for the
Code 128 symbology.
Variable Length —
For variable length decoding, a minimum and maximum length
may be set.
Fixed Length —
For fixed length decoding, two different lengths may be set.
ENTER/EXIT PROGRAMMING MODE
Code 128 Length Control = Variable Length
Code 128 Length Control = Fixed Length
DEFAULT

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic QD2100 and is the answer not in the manual?

Datalogic QD2100 Specifications

General IconGeneral
Scanner TypeLinear Imager
Environmental SealingIP42
Operating Temperature0 to 50 °C / 32 to 122 °F
Scan Rate270 scans/sec
InterfaceRS-232, Keyboard Wedge, USB
Drop ResistanceWithstands drops from 1.5 m / 5.0 ft onto concrete
Print Contrast Ratio15%
Decode CapabilityAll standard 1D barcodes
Resolution0.102 mm / 4 mils
Storage Temperature-20 to 70 °C / -4 to 158 °F
Humidity5 to 95% non-condensing
Electrical SafetyEN60950-1
EMCEN 55022
Light SourceLED (red)
