RS-232 ONLY Interface
44 QuickScan® QD2100
Stop Bits
The stop bit(s) at the end of each transmitted character marks the end of transmission of
one character and prepares the receiving device for the next character in the serial data
stream. The number of stop bits selected (one or two) depends on the number the receiv-
ing terminal is programmed to accommodate. Set the number of stop bits to match host
device requirements.
ENTER/EXIT PROGRAMMING MODE
1 Stop Bit
2 Stop Bits
DEFAULT

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic QD2100 and is the answer not in the manual?

Datalogic QD2100 Specifications

General IconGeneral
Scanner TypeLinear Imager
Environmental SealingIP42
Operating Temperature0 to 50 °C / 32 to 122 °F
Scan Rate270 scans/sec
InterfaceRS-232, Keyboard Wedge, USB
Drop ResistanceWithstands drops from 1.5 m / 5.0 ft onto concrete
Print Contrast Ratio15%
Decode CapabilityAll standard 1D barcodes
Resolution0.102 mm / 4 mils
Storage Temperature-20 to 70 °C / -4 to 158 °F
Humidity5 to 95% non-condensing
Electrical SafetyEN60950-1
EMCEN 55022
Light SourceLED (red)
