Product Reference Guide 267
Appendix A
Technical Specifications
Table 35 contains Physical and Performance Characteristics, User Environment and
Regulatory information. Table 36 provides Standard Cable Pinouts.
Table 35. Technical Specifications
Item Description
Physical Characteristics
Dimensions
2.8 in. H x 6.7 in. L x 2.6 in. W
(7.1 cm H x 17.1 cm L x 6.6 cm W)
Weight (without cable) Approximately 4.2 oz. (119 g)
Color Black or White
Electrical Characteristics
Voltage & Current
QD2110 4-14 VDC
QD2130 5.0 VDC +/-10%
180mA @ 5V Typical Idle
345mA @ 5V Typical Scanning
Performance Characteristics
Light Source 617nm LEDs
Roll (Tilt) Tolerance ± 45° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 65°
Scan Angle 43° ± 3°
Depth of Field
4.0 mil 3.0 - 9.5 cm
5.0 mil 2.3 - 14 cm
7.5 mil 1.5 - 26.5 cm
10 mil (80% UPC) 1.3 - 37.5 cm
13 mil (100% UPC) 2.5 - 46.5 cm
15 mil to 48 cm
20 mil to 59 cm
Minimum Element Width 3 mil
Print Contrast Minimum 15% minimum reflectance
