Datalogic QD2100 User Manual

Error Codes
Product Reference Guide 285
Error Codes
Upon startup, if the imager sounds a long tone, this means the imager has not passed its
automatic Selftest and has entered FRU
1
isolation mode. If the imager is reset, the se-
quence will be repeated. The following table describes the LED flashes/beep codes asso-
ciated with an error found.
1. Field Replaceable Unit (FRU)
NUMBER OF LED
FLASHES/BEEPS
ERROR CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for assistance
2 Interface PCB
4 Imager Module
5 [Reserved]
6Digital PCB
14 CPLD/Code Mismatch

Datalogic QD2100 Specifications

General

Scanner Type	Linear Imager
Environmental Sealing	IP42
Operating Temperature	0 to 50 °C / 32 to 122 °F
Scan Rate	270 scans/sec
Interface	RS-232, Keyboard Wedge, USB
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft onto concrete
Print Contrast Ratio	15%
Decode Capability	All standard 1D barcodes
Resolution	0.102 mm / 4 mils
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Humidity	5 to 95% non-condensing
Electrical Safety	EN60950-1
EMC	EN 55022
Light Source	LED (red)
