Datalogic QD2100 User Manual

Configuring the Interface
Product Reference Guide 13
KEYBOARD FEATURES
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Standard Key Encoding
Select KBD-AT
Set KEYBOARD
WEDGE
Interface
Features
starting on page
67
Select KBD-AT-NK
Keyboard Wedge for IBM AT PS2 with standard key
encoding but without external keyboard
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Alternate Key
Select KBD-AT-ALT
Select KBD-AT-ALT-NK
Keyboard Wedge for IBM AT PS2 with alternate key
encoding but without external keyboard
PC/XT w/Standard Key Encoding
Select KBD-XT
Select KBD-IBM-3153
Keyboard Wedge for IBM Terminal 3153

Datalogic QD2100 Specifications

General

Scanner Type	Linear Imager
Environmental Sealing	IP42
Operating Temperature	0 to 50 °C / 32 to 122 °F
Scan Rate	270 scans/sec
Interface	RS-232, Keyboard Wedge, USB
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft onto concrete
Print Contrast Ratio	15%
Decode Capability	All standard 1D barcodes
Resolution	0.102 mm / 4 mils
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Humidity	5 to 95% non-condensing
Electrical Safety	EN60950-1
EMC	EN 55022
Light Source	LED (red)
