UPC-E

Product Reference Guide

117

UPC-E — cont.

UPC-E Number System Character Transmission

This feature enables/disables transmission of the UPC-E system number character.

ENTER/EXIT PROGRAMMING MODE

UPC-E Number System Character = Do not transmit

UPC-E Number System Character = Transmit

DEFAULT
