EAN 13

Product Reference Guide

121

EAN 13 — cont.

EAN-13 Flag 1 Character

Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character

is the first character of the label.

ENTER/EXIT PROGRAMMING MODE

EAN-13 Flag 1 Char= Don’t transmit

EAN-13 Flag 1 Char= Transmit

DEFAULT
