Datalogic RIDA DBT6400 Quick Reference Guide

Linking to a Host
Quick Reference Guide 7
Linking to a Host
The RIDA DBT6400 is equipped with Bluetooth® Wireless
Technology. To set up the scanner for communication
with a Host the user shall select the Profile Mode.
The available Profile Mode for standard Bluetooth are:
• Bluetooth Serial Port Profile (SPP)
• Bluetooth HID Profile (default)
Scan one of the following barcodes to select the desired
Profile Mode:
.
After reading one of the above profile label, the scanner, if
already connected to a Host, will unlink.
NOTE
If the profile label is read when the reader is
already connected to a Host, the scanner will
first unlink and then apply the new profile.
After reading the profile label the scanner will
become discoverable by the Host.
Link to Host in SPP mode
Link to Host in HID mode

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
