Datalogic RIDA DBT6400 Quick Reference Guide

Support Through the Website
48 RIDA™ DBT6400
Support Through the Website
Datalogic provides several services as well as technical
support through its website.
Log on to www.datalogic.com and click on the SUPPORT >
GENERAL DUTY HANDHELD SCANNERS category link.
From this page you can select your product model from
the dropdown list which gives you access to:
Downloads including Data Sheets, Manuals, Software &
Utilities, and Drawings;
Repair Program for On-Line Return Material Authoriza-
tions (RMAs) plus Repair Center contact information;
Service Program containing details about Maintenance
Agreements;
Technical Support through email or phone.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
