Datalogic RIDA DBT6400 Quick Reference Guide

Quick Reference Guide i
Table of Contents
END USER LICENSE AGREEMENT ............................................. iii
Description .................................................................................... 1
Setting Up the Reader ................................................................. 3
Configuring the BC6020 Base Station .............................. 3
Using the BC6020 Base Station ......................................... 4
Charging the Batteries ....................................................... 5
Replacing the Battery Pack ................................................ 6
Linking to a Host .......................................................................... 7
Bluetooth Pairing....................................................... 8
Bluetooth Unpairing .................................................. 8
Passkey Request ....................................................... 9
Linking to a Base Station ..........................................................10
Compatibility ...............................................................................11
Supported BT Specification .............................................. 11
Device and operative system supported ........................11
Tested Devices ..................................................................12
Using the RIDA DBT6400 ...........................................................13
Programming ..............................................................................15
Using Programming Bar Codes .......................................15
Configure Other Settings ..................................................15
Resetting Standard Product Defaults ............................ 15
Power Off ...........................................................................16
Audio Jingle ........................................................................ 16
Viber ...................................................................................18
RGB LED Settings .............................................................. 19
HID Alt Mode ......................................................................21
HID Country Mode ......................................................................22
Selecting the Base Interface Type ............................................ 24
Configuring the Interface .................................................24
Reading Parameters ..................................................................26
Aiming System ..................................................................26
Good Read Green Spot Duration .....................................26
Scan Modes ................................................................................28
Pick Mode ...........................................................................30
Multiple Label Reading .....................................................30
Good Transmission Beep .................................................31
Batch Mode ........................................................................ 32
Power Saving .....................................................................34
Technical Features ..................................................................... 35
LED and Beeper Indications ......................................................39
Base Station Indications ...........................................................42
Datalogic Limited Factory Warranty ...............................43

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
