Datalogic RIDA DBT6400 - Using the RIDA DBT6400

Using the RIDA DBT6400
Quick Reference Guide 13
Using the RIDA DBT6400
The RIDA DBT64XX normally functions by capturing and
decoding codes. The aiming system is activated on trigger
pull and indicates the center of the field of view which
should be positioned over the bar code:
Aiming System
Relative Size and Location of Aiming System Pattern
Linear bar code
2D Matrix symbol
