Quick Reference Guide 1
RIDA DBT6400
Description
The RIDA DBT6400 by Datalogic is a Bluetooth Companion
reader (2D Imager) that enables real-time barcode scan-
ning into any Bluetooth ready device including Android,
iOS and Windows.
Thanks to its extremely reduced size, the DBT6400 fits
easily into a pocket and is the ideal choice for applications
like field sales and service, inventory management, retail
point-of-sale (POS), Healthcare and many more.
The attractive design and the light weight that character-
ize the DBT6400 allow the scanner to be easily worn
around the user’s neck with the lanyard supplied or
clipped in a pocket.
Datalogic’s exclusive patented ‘Green Spot’ for good read
feedback helps to improve productivity in noisy environ-
ments or in situations where silence is required.
The RIDA DBT6400 has several customizable features:
the reader's attractive illumination changes color to
indicate its status and can be personalized by the
user.
the option to use personal jingles (a short user-
defined tune uploaded via Datalogic Aladdin™ con-
figuration software) instead of the normal beep
tone.
The RIDA DBT6400 can be used with his Bluetooth base
station BC6020. The base station can be used for place-
ment of the DBT6400 allowing for charging and Host
wired connection.
The scanner is available in the following configurations:
DBT6400-HC Healtcare, cordless Bluetooth.
DBT6400-BK Black, cordless Bluetooth.
The scanner with the Bluetooth base station is available
in the following configurations:
DBT6420-HC Healtcare, cordless Bluetooth,KIT.
DBT6420-BK Black, cordless Bluetooth,KIT.

Other manuals for Datalogic RIDA DBT6400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic RIDA DBT6400 and is the answer not in the manual?

Datalogic RIDA DBT6400 Specifications

General IconGeneral
Scanner typeHandheld scanner
TypeHandheld bar code reader
Wavelength650 nm
Sensor type-
Yaw reading angle-60 - 60 °
Tilt reading angle0 - 360 °
Pitch reading angle-65 - 65 °
Linear (1D) barcodes supportedJAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range25 m
Bluetooth version4.0
Operating frequency2400 MHz
Standard interfacesBluetooth, USB
Connectivity technologyWired & Wireless
Battery life5 h
Charging time2.5 h
Battery capacity700 mAh
Power source typeBattery
Number of reads per charge3000
Number of batteries supported1
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 95 %
Product colorWhite
International Protection (IP) codeIP50
Sustainability certificatesRoHS
Cables includedNo
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth42.3 mm
Width112.5 mm
Height27.5 mm
Weight85 g
