Datalogic RIDA DBT6400 - Batch Mode

Scan Modes
32 RIDA™ DBT6400
Batch Mode
The reader can be programmed to work in batch mode.
The allowed batch modalities are:
• Automatic batch mode: when paired with a remote
host or base, but currently not connected (i.e. due
to an out of range event), the reader stores a label
inside the batch queue. As soon as the reader is
able to reconnect to the remote host, the batch
queue is transmitted to the host.
• Manual batch mode: the reader puts the decoded
bar code in the batch queue, independently from
the connection status. To transmit the batch queue
to a connected host, or to delete the queue, it is
possible to read the dedicated configuration label.
BATCH MODE
ENTER/EXIT PROGRAMMING MODE
 Batch Disable
Automatic Batch
Manual Batch
$CBTBM00\x0d
$CBTBM01\x0d
$CBTBM02\x0d
