Datalogic RIDA DBT6400 Quick Reference Guide

Technical Features
38 RIDA™ DBT6400
Decode Capability
1D Bar Codes
UPC/EAN/JAN (A, E, 13,8); UPC/EAN/JAN (including P2 /P5); UPC/
EAN/JAN (including; ISBN / Bookland & ISSN); UPC/EAN Coupons;
Code 39 (including full ASCII); Code 39 Trioptic; Code39 CIP (French
Pharmaceutical); LOGMARS (Code 39 w/ standard check digit
enabled); Danish PPT; Code 32 (Italian Pharmacode
39); Code 128; Code 128 ISBT; Interleaved 2 of 5; Standard 2 of 5;
Interleaved 2 of 5 CIP (HR); Industrial 2 of 5; Discrete 2 of 5; Matrix
2 of 5; IATA 2of5 Air cargo code; Code 11; Codabar; Codabar (NW7);
ABC Codabar; EAN 128; Code 93; MSI; PZN; Plessey; Anker Plessey;
GS1 DataBar Omnidirectional; GS1 DataBar Limited; GS1 DataBar
Expanded; GS1 DataBar Truncated; DATABAR Expanded Coupon.
2D / Stacked Codes
The RIDA DBT6400 scanner is capable of decoding the following
symbologies using multiple frames (i.e. Multi-Frame Decoding):
Datamatrix; Inverse Datamatrix; Datamatrix is configurable for
the following parameters:; Normal or Inverted; Square or Rectan-
gular Style; Data length (1 - 3600 characters); Maxicode; QR Codes
(QR, Micro QR and Multiple QR Codes); Aztec; Postal Codes - (Aus-
tralian Post; Japanese Post; KIX Post; Planet Code; Postnet; Royal
Mail Code (RM45CC); Intelligent Mail Barcode (IMB); Sweden Post;
Portugal Post); LaPoste A/R 39; PDF-417; MacroPDF; Micro
PDF417; GS1 Composites (1 - 12); French CIP13
a
; GS1 DataBar
Stacked; GS1 DataBar Stacked Omnidirectional; GS1 DataBar
Expanded Stacked; GSI Databar Composites; Chinese Sensible
Code; Inverted 2D codes
b
.
a. It is acceptable to handle this with ULE.
b. The SW can apply the Normal/Reverse Decoding Control to the following
symbologies: Datamatrix, QR, Micro QR, Aztec and Chinese Sensible Code.

Datalogic RIDA DBT6400 Specifications

General

Scanner type	Handheld scanner
Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	-
Yaw reading angle	-60 - 60 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	JAN, PostBar, RM4SCC / KIX
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Wireless range	25 m
Bluetooth version	4.0
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Battery life	5 h
Charging time	2.5 h
Battery capacity	700 mAh
Power source type	Battery
Number of reads per charge	3000
Number of batteries supported	1
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	White
International Protection (IP) code	IP50
Sustainability certificates	RoHS
Cables included	No
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	42.3 mm
Width	112.5 mm
Height	27.5 mm
Weight	85 g
