LED and Beeper Indications
Quick Reference Guide 41
Programming Mode - The following indications ONLY occur
when the reader is in Programming Mode
.
Indication Description LED Beeper
Label Program-
ming Mode Entry
A valid program-
ming label has been
scanned.
Top LED
blinks con-
tinuously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of Partial
Label
In cases where
multiple labels
must be scanned to
program one fea-
ture, this indication
acknowledges each
portion as it is suc-
cessfully scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and cur-
rent volume.
Label Program-
ming Mode Accep-
tance of
Programming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Program-
ming Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
