TECHNICAL FEATURES
5
Environmental Features
Working temperature** -10° to + 50 °C / 14° to +122 °F
Storage temperature -20° to +70 °C / -4° to +158 °F
Humidity*** 90% non condensing for temperatures<40°C
Protection IP64
ESD protection 4 KV contact discharge, 8 KV air discharge
Drop resistance**** 1.5 m / 5 ft
Mechanical Features
Dimensions (LxWxH) Datalogic Skorpio™ only: 19.6 x 7.7 x 3.3 cm / 7.7 x
3.0 x 1.3 in
Datalogic Skorpio-GUN™ only: 19.6 x 7.7 x 15.8 cm
/ 7.7 x 3.0 x 6.2 in
Weight (depending on model) Datalogic Skorpio™ only: 310 - 360 g / 10.9 - 12.7
oz (incl. battery)
Datalogic Skorpio-GUN™ only: about 560 g / 19.7
oz (incl. battery)
** Close to the limits of the working temperature, some display and/or battery performance
degradation may occur.
*** Multiple rapid humidity and/or temperature variations may cause condensing.
**** Multiple drops can permanently damage the device.
Programming Features
Operating system* Windows CE 5.0 Professional / Windows Mobile 6.1
Professional
Laser Models
Decoded barcodes 1D UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39
Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of
5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI,
Plessey, Code 93, Code 11
Laser Optical Features 7XX-9XX/ 5XX-9XX 7XX-2XX
Maximum resolution 0.10 mm / 4 mils 0.25 mm / 10 mils
Skew angle ± 50°
Pitch angle ± 65°
Scan rate - bidirectional 104 ± 12 scan/sec 35 ± 5 scan/sec
Light source laser scanner VLD, wavelength in the range 630 to 680 nm
Safety class Class II EN 60825-1/CDRH
* Depending on models.
87
