TEACHING
PRODUCT REFERENCE GUIDE 12
Step 2: Acquire GOOD
On the Acquire GOOD page, if the triggered mode is not enabled, one or more GOOD
objects can be acquired by clicking on the Teach button. If the triggered mode is
enabled, there will be two buttons: CONTINOUS and START. When START button is
clicked, every image acquired will be added to the GOOD objects. Clicking instead the
CONTINOUS button, the Smart-VS will switch working like when the triggered mode was
not enabled.
It is recommended to acquire as many GOOD images as the known number of instances
to be treated as GOOD.
After adding at least one object, you can click Next and go to the Acquire NO GOOD
page.
NOTE: The GOOD and NO GOOD boxes can store a total of 20 images, of
which at least one per box. This means that each box can have a maximum
of 19 images.
NOTE: Click on an acquired object in the GOOD box and select DELETE to
delete it.
