45 SMART-VS PLUS
APPENDIX A
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage 10 to 30 Vdc
Consumption 0.40 - 0.14 A (4.2 W) max
Communication Interfaces
Ethernet (embedded)
a
a. The embedded Ethernet interface is intended for configuration only through connection to the
device IP address 192.168.3.100. Point-to-Point connection is recommended.
10/100 Mbit/s
Inputs
Opto-coupled and polarity insensitive
Max. Voltage 30 Vdc
Max. Input Current 10 mA
Outputs
PP, NPN or PNP short circuit protected;
Max. Output Voltage Drop 3V
V
OUT
HIGH (Max. / Min.)
V
supply
/ V
supply
- 3V
V
OUT
LOW (Max. / Min.)
3V / 0V
I
LOAD
Max.
100 mA
OPTICAL FEATURES
Operating Distance
50 - 150 mm
View Angle
19°
