47 SMART-VS PLUS
APPENDIX B
TCP/IP COMMUNICATION
CONNECTION
The TCP/IP communication requires that a connection be initiated between the two
devices. The Smart-VS (server) is listening on port 1023 and the PLC or PC (clients), must
send a connection request to establish communication. When the communication is
established, commands can be sent to the device.
Figure 20: Connection to device
Client
System Controller
or
PC
Smart-VS
(Server)
Connection
Connection accepted
