Datamax A-Class A-6310 User Manual

A-Class 5
1.2 Index to Features and Controls
Important printer parts are highlighted in the table and drawings below:
Item Number Description
1 Control Panel
2 Power Switch
3 Access Cover
4 Power Receptacle
5 GPI/O Port A
6 Serial Port
7 USB Port
8 Parallel Port
9 GPI/O Port B
10 Ribbon Take-Up Hub*
11 Ribbon Supply Hub*
12 Upper Media Post
13 Lower Media Post
14 Cover Sensor
15 Upper Ribbon Idler
16 Leveling Cam
17 Printhead Assembly
18 Peel Bar
19 Platen Roller
20 Head Lift Lever
21 Media Sensor
22 Media Sensor Adjustment Knob
23 Media Guide
24 Peel Assembly Release Lever
25 Locking Post
26 Peel Assembly
27 COM D
28 COM C
* Optional equipment
